AUIRS1170STR New And Original SOP8 Integrated Circuit

AUIRS1170STR New And Original SOP8 Integrated Circuit

AUIRS1170STR Integrated Circuit

SOP8 Package Ic Integrated Circuit

AUIRS1170STR Ic Chip

Place of Origin:

original

Brand Name:

INFINEON

Model Number:

AUIRS1170STR

Contact Us

Request A Quote
Product Details
Product Model:
AUIRS1170STR
Package / Box::
SOP8
Country Of Origin:
Original Genuine, Brand New, Unused
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiate
Packaging Details
SOP8
Delivery Time
3
Stock
8000+
Payment Terms
L/C, D/A, D/P, T/T
Supply Ability
50000PCS
Product Description

ISO9001.pdf

AUIRS1170STR is a high voltage driver at the automotive level, with the following main parameters:
Working voltage range: 6V to 20V
Maximum output peak voltage: 600V
Maximum output peak current: 250mA
Working temperature range: -40 ℃ to 150 ℃
Packaging: SOP8
The following are some applications of AUIRS 1170STR:
Automotive Electronics: AUIRS1170STR can be used for motor control, ignition system, lighting control, etc. in automotive electronics.
Industrial control: Due to its high voltage output and high-temperature working characteristics, AUIRS1170STR can also be used for motor control, high-voltage charging control, etc. in industrial control.
Conclusion: AUIRS1170STR is a high-voltage driver suitable for various application scenarios such as automotive electronics and industrial control. It has a wide operating voltage range, high output peak voltage and peak current, and can meet the needs of different application scenarios. It is packaged as SOP8
Suitable for SMT mounting.


Product Technical Specifications
EU RoHS Compliant
ECCN (US) EAR99
Part Status Obsolete
HTS 8542.39.00.01
Automotive Yes
PPAP Unknown
Bridge Type Half Bridge
Number of Drivers 1
Type MOSFET
Number of Outputs 1
Maximum Rise Time (ns) 70(Typ)
Maximum Fall Time (ns) 35(Typ)
Maximum Operating Frequency (kHz) 500
Maximum Propagation Delay Time (ns) 120
Minimum Operating Supply Voltage (V) 11
Maximum Operating Supply Voltage (V) 18
Maximum Supply Current (mA) 80
Peak Output Current (A) 6(Typ)
Maximum Power Dissipation (mW) 970
Minimum Operating Temperature (°C) -25
Maximum Operating Temperature (°C) 125
Special Features Undervoltage Lockout
Latch-Up Proof No
Packaging Tape and Reel
Mounting Surface Mount
Package Height 1.25(Min)
Package Width 3.9
Package Length 4.9
PCB changed 8
Standard Package Name SO
Supplier Package SOIC N EP
Pin Count 8
Lead Shape Gull-wing
