Place of Origin:
original
Brand Name:
TI
Model Number:
OPA2188AQDGKRQ1
Contact Us
OPA2188AQDGKRQ1 is an automotive grade precision operational amplifier, with the following main parameters:
Working voltage range: 2.7V to 36V
Bandwidth: 1.5MHz
Input bias current: 2nA
Working temperature range: -40 ℃ to 125 ℃
Packaging: VSSOP-8
The following are some applications of OPA2188AQDGKRQ1:
Automotive Electronics: OPA2188AQDGKRQ1 can be used for power management, sensor signal amplification, control loops, and more in automotive electronics.
Industrial control: Due to its high precision and wide working voltage range, OPA2188AQDGKRQ1 can also be used for signal amplification, sensor signal processing, and other applications in industrial control.
Conclusion: OPA2188AQDGKRQ1 is a high-precision and high-performance precision operational amplifier suitable for various application scenarios such as automotive electronics and industrial control. It has a wide operating voltage range, low input bias current, and high bandwidth, which can meet the needs of different application scenarios. Its packaging is VSSOP-8, suitable for SMT mounting.
| Product Technical Specifications | |
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Automotive | Yes |
| PPAP | Yes |
| Type | Low Noise Amplifier |
| Manufacturer Type | Low Noise Amplifier |
| Number of Channels per Chip | 2 |
| Rail to Rail | Rail to Rail Output |
| Maximum Input Offset Voltage (mV) | 0.025@36V |
| Minimum Single Supply Voltage (V) | 4 |
| Typical Single Supply Voltage (V) | 5|9|12|15|18|24|28 |
| Maximum Single Supply Voltage (V) | 36 |
| Minimum Dual Supply Voltage (V) | ±2 |
| Typical Dual Supply Voltage (V) | ±3|±5|±9|±12|±15 |
| Maximum Dual Supply Voltage (V) | ±18 |
| Maximum Input Offset Current (uA) | 0.0028@36V |
| Typical Input Bias Current (uA) | 0.00016@36V |
| Maximum Input Bias Current (uA) | 0.0014@36V |
| Maximum Quiescent Current (mA) | 1.02@卤18V |
| Power Supply Type | Single|Dual |
| Typical Slew Rate (V/us) | 0.8@36V |
| Typical Input Noise Voltage Density (nV/rtHz) | 8.8@36V |
| Typical Voltage Gain (dB) | 136 |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.007@36V |
| Minimum PSRR (dB) | 142.5(Typ) |
| Minimum CMRR (dB) | 120 |
| Minimum CMRR Range (dB) | >=115 |
| Typical Gain Bandwidth Product (MHz) | 2 |
| Typical Settling Time (ns) | 27000 |
| Shut Down Support | No |
| Minimum Operating Temperature | -40 |
| Maximum Operating Temperature | 125 |
| Supplier Temperature Grade | Automotive |
| Mounting | Surface Mount |
| Package Height | 0.95(Max) |
| Package Width | 3.1(Max) |
| Package Length | 3.1(Max) |
| PCB changed | 8 |
| Standard Package Name | SOP |
| Supplier Package | VSSOP |
| Pin Count | 8 |
| Lead Shape | Gull-wing |
